Trek Madone Sl 5 M Gen 8 Bike Matte Deep Smoke

Madone SL 5 Gen 8 is a lightweight aero road bike that brings elite racing tech to a lower price point. It offers similar aero benefits to the pricier Madone SLR Gen 8, but with a more economical OCLV 500 Carbon layup and two-piece cockpit with hidden cable routing. It's built to race, with geometry that keeps you quick on the sprints yet in control on fast descents. A Shimano 105 groupset keeps the price down while still delivering clean mechanical shifting you can trust.

Highlights :

• Frame: 500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chainkeeper, T47 BB, flat mount disc, UDH, 142x12mm thru axle
• Fork: Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
• Max Compatible Fork Travel: 100mm (XS & S: 490mm axle-to-crown, M & up: 509mm axle-to-crown)
• Hub Front: Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle
• Skewer Front: Bontrager Switch chamfered thru axle, removable lever
• Hub rear: Bontrager alloy, sealed bearing, centerlock disc, Shimano 11-speed freehub, 142x12mm thru axle
• Skewer rear: Size XS, S, M, ML, L, XL : Bontrager Switch chamfered thru axle, removeable lever
• Rim: Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21mm width, Presta valve
• Spokes: 14g stainless steel, black
• Tire: Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x28mm
• Max Tire Size: 32mm (as measured, see manual for details)
• Shifter: Shimano 105 R7120, 12 Speed
• Front derailleur: Shimano 105 R7100, braze-on, down swing
• Rear derailleur: Shimano 105 R7100, 36T max Cog
• Crank: Size: M: Shimano 105 R7100, 50/34, 170 mm length
• Crank: Size: M: Shimano RS520, 50/34, 170 mm length
• Bottom Bracket: Praxis, T47 threaded, internal bearing
• Cassette: Shimano 105 7101, 11-34, 12 speed
• Chain: Shimano SLX M7100, 12 Speed
• Max chainring size: 1x: 54T, 2x: 56/43
• Saddle: Size XS, S, M, ML, L, XL : Verse Short, steel rails, 145mm width
• Saddle: Size M, ML, L, XL : Bontrager Aeolus Comp, steel rails, 145mm width
• Seatpost: Size: XS,S, M, XL : Madone aero carbon seatpost, 0mm offset, short length
• Handle Bar: Size: S, M : Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 38cm control width, 42cm drop width
• Handlebar Tape: Trek EcoTack, black
• Grips: Bontrager XR Endurance Comp, Lock-on
• Stem: Size: S, M: Trek RCS Pro, -7 degree, 90mm length
• Brake rotor: Shimano RT70, centerlock, 160 mm
• Rotor size: Max brake rotor sizes 180 mm front, 160 mm rear

Composition :

• Aluminium

Color: Matte Deep Smoke

Product Code : 5319898
